The Carlson CRT is a highly accurate and fast An-droid robotic station. It features a rotation speed of 180°/sec and an EDM accuracy of 1 mm + 1 ppm, with a range of up to 1000 m without a prism. The CRT is available in two versions, 1” and 2” second. For both models, the quietness and smoothness in prism searches and rotations are among the most observed and appreciated features.
Equipped with the Android operating system, the CRT has an onboard software. This enables users to navigate online and interact with the touch screen in an easy and familiar way.
Carlson CRT can be bundled with the GNSS receiver, Carlson or any other supported in our field software, for a hybrid system. Working in hybrid mode in Carlson SurvPC data collection software offers the GPS Search routine, possibility of measuring the prism on a tilted pole and other advanced hybrid functionality.
Carlson CRT Robotic Total Station Data Sheet
Carlson CRT Robotic Total Station
- TDRIVE MOTOR, FAST AND SILENT: The CRT Robotic total station boasts a rotation speed of 180°/sec, making it one of the fastest in Its product category. Not only Is it speedy, but it Is also impressively quiet, with noise levels among the lowest in its class. Additionally, the Tdrive technology, with a very highspeed motor, allows for high-speed pursuit, even with a prism installed on moving vehicles. Not using gear technology ensures frictionless movement, greater durability, and less maintenance.
- HIGH ACCURACY AND PROFESSIONAL RESULTS: This instrument is top-of-the-line. Its detailed engineering allows for exceptional performance, achieving an accuracy of 1 mm + 1 ppm with a prism, at a measurement speed of significantly less than one second.
- LONG DISTANCE REFLECTORLESS: CRT guarantees high accuracy long range measurements: up to 1000 m in reflectodess mode and up to 6000 m using a single prism, with millimeter accuracy.
